VT-620 Visual ODS™ is the base for all other ME’scope Packages

An animated ODS shows how your machine or structure is moving in slow motion. By animating the ODS’s of a structure, you can see what can’t be seen any other way; a structure’s overall motion and the motion of one part relative to another. Excessive vibration levels and loose or damaged parts are easily identified from an animated ODS display.

The Visual ODS Pro™ package combines all of the features of the Visual ODS™ package with the features of the VES-3000 Signal Processing option.  The Signal Processing option includes an FFT for analyzing data in either the time or frequency domain, plus waveform cut, copy and paste, and many other signal processing features.

The Visual Modal™ package combines all of the features of theVisual ODS Pro™ package with the features of the VES-4000 Basic Modal Analysis option.  The Basic Modal Analysis option provides all of the tools you need for extracting modal parameters from experimental vibration measurements (FRFs). With Visual Modal™ you can identify the frequency, damping & mode shape of the modes of a structure from experimental data.

The Visual Modal Pro™ package combines the features of theVisual Modal™ package with the features of both the VES-4500 Multi-Reference Modal Analysis and VES-3500 MIMO Modeling & Simulation options.

The Visual OMA™ package combines all of the features of aVisual Modal™ package with the features of the VES-4700 Operational Modal Analysis option.  For cases where the excitation forces cannot be measured and output-only responses can be acquired, modal parameters can still be extracted from a set of specially processed Cross Spectra or ODS FRFs.

The Visual OMA Pro™ package combines the features of theVisual Modal Pro™ package with the features of the VES-4700 Operational Modal Analysis option.  For cases where the excitation forces cannot be measured and output-only responses are acquired, modal parameters can still be extracted from a set of specially processed Cross Spectra or ODS FRFs.

The Visual Acoustics™ package includes all of the features of the Visual ODS™ package, plus the features of the VES-6000 Acoustics option.  With this package, you can post-process and display in animation Acoustic Intensity, Sound Pressure Level (SPL), Sound Power, and ODS’s from either Octave or Narrow Band measurements.  Vibro-acoustic data (acoustics & vibration), can be displayed on the same structure model, thus allowing you to correlate surface vibration with acoustic field measurements.

The Visual Vibro-Acoustics™ package combines all of the features of the Visual Modal™ package with the features of theVES-6000 Acoustics option.

The Visual SDM™ package combines all of the features of theVisual Modal™ package with the features of the VES-5000 Structural Dynamics Modification option.

The Visual SDM Pro™ package combines all of the features of the Visual Modal Pro™ package with the features of the VES-5000 Structural Dynamics Modification option.

The Visual Experimental FEA™ package combines the features of a Visual SDM Pro™ package with the features of the VES-8000 Experimental FEA (Finite Element Analysis) option. With the Experimental FEA option you can create an FEA model by adding FEA elements to the same model that is used to display ODS’s and mode shapes in animation.

The Visual STN™ package combines the features of the Visual ODS™ package with the features of all of the following Visual Engineering Series options;
